AFB0512LD by delta thermal / emi / solenoids
Image is representational - see mfr. specs

AFB0512LD

Delta Thermal / EMI / Solenoids

DC Fan Ball Bearing 12V 0.06A 0.72W 4000RPM 10.98CFM 25dB Flange Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AFB0512LD is a 12V DC axial fan designed for efficient thermal management and cooling applications. It features a 50 x 50 x 20 mm form factor with two ball bearings, plastic impeller and frame (UL 94V-0 rated), and operates at 4000 RPM with a maximum air flow of 0.311 m³/min (10.98 CFM) and maximum air pressure of 2.42 mmH2O (0.095 IN H2O). The fan operates within a voltage range of 7.0 to 13.8V, draws 0.06A at rated conditions, and consumes 0.72W of input power, producing 25.0 dB-A noise level. With its compact dimensions, low power consumption, and reliable bearing design, the AFB0512LD is ideal for server cooling, industrial equipment ventilation, and embedded system thermal management where space and energy efficiency are critical.

Search Keywords: AFB0512LD

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB0512LD
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
252
Category:
DC Fan
Dimension:
50 x 50 x 20 mm
Voltage Rating:
12 V
Power Rating:
0.72 W
Maximum Airflow:
10.9CFM
Noise Level:
25 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 80

Ships today, if you order in

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
5
$16.21
10
$12.88
25
$12.28
50
$11.19
63
$10.75
126
$10.24
189
$10.18
252 +
$10.12
