AFB0712SHX02 by delta thermal / emi / solenoids
Image is representational - see manufacturer specifications
Delta Thermal / EMI / Solenoids Authorized Distributor

AFB0712SHX02

Axial Square-70mm L x 70mm H x 25.4mm W 12VDC 4 Wire Leads Speed Sensor (Tach) PWM Control ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AFB0712SHX02 is a DC brushless axial flow fan designed for thermal management applications requiring reliable cooling performance. It operates at a rated voltage of 12 VDC with an operating range of 5.0 to 13.8 VDC, delivering a maximum airflow of 1.729 m³/min (61.05 CFM) at zero static pressure and a maximum air pressure of 15.90 mmH2O at zero airflow. The fan features PWM speed control capability with a frequency range of 20–30 kHz (preferred 25 kHz), allowing dynamic speed adjustment from 1000 RPM (0% duty cycle) to 6300 RPM (100% duty cycle), and includes a frequency generator (FG) signal output for speed monitoring. Built with a plastic frame and impeller (UL 94V-0), two ball bearings, and comprehensive protection features including locked rotor protection and polarity protection, the fan is rated for 70,000 hours continuous operation at 40°C with 15–65% RH. This fan is ideal for computer systems, industrial equipment, and applications requiring efficient thermal management with variable speed control.

Search Keywords: AFB0712SHX02

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB0712SHX02
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
162
Category:
DC Fan
Dimension:
70 x 70 x 25.4 mm
Voltage Rating:
12 V
Power Rating:
7.8 W
Maximum Airflow:
61.05 CFM
Noise Level:
50.5 dB
Special Features:
N/A
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

IN STOCK: 0

On Order: 245   can ship 12/3/26
On Order: 648   can ship 3/29/27

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 162

Factory Lead-Time 40 Weeks

Price (USD)

Qty
Unit Price
5
$34.22
50
$34.13
100
$34.05
162
$33.97
324
$17.92
486
$12.33
648 +
$12.08
Supplier's Standard Package
