AFB0724VH-AF00 by delta thermal / emi / solenoids
Image is representational - see mfr. specs

AFB0724VH-AF00

Delta Thermal / EMI / Solenoids

DC Fan Axial Ball Bearing 24V 14V to 26.4V 51.97CFM 47.5dB 70 X 70 X 25.4mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AFB0724VH-AF00 is a DC brushless axial flow fan designed for efficient thermal management in electronic equipment. The fan operates at a rated voltage of 24 VDC with an operating range of 14.0 to 26.4 VDC, delivering a maximum air flow of 1.472 M³/MIN (51.97 CFM) at zero static pressure and a maximum air pressure of 10.99 mmHg2O at zero airflow. It features a two-phase, four-pole motor configuration running at 5500 RPM ±10% with low acoustic noise of 47.5 dB-A average, and incorporates two ball bearings for reliable long-term operation. The fan is constructed with UL 94V-0 plastic frame and impeller, includes locked rotor protection, and is rated for 70,000 hours of continuous operation at 40°C. It is commonly used in server cooling, industrial equipment, and telecommunications systems where reliable thermal management and low noise operation are essential.

Search Keywords: AFB0724VHAF00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB0724VH-AF00
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
162
Category:
DC Fan
Dimension:
70 x 70 x 25.4 mm
Voltage Rating:
24 V
Power Rating:
6.48 W
Maximum Airflow:
51.97 CFM
Noise Level:
47.5 dB
Special Features:
N/A
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

IN STOCK: 440

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 162

Factory Lead-Time 32 Weeks
