AFB1212SHE by delta thermal / emi / solenoids

AFB1212SHE

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 120x38mm - 12VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AFB1212SHE is a DC Axial Fan. Voltage - Rated 12VDC Size / Dimension Square - 120mm L x 120mm H Width 38.00mm Air Flow 151.9 CFM (4.25m³/min) Static Pressure 0.571 in H2O (142.2 Pa) Bearing Type Ball Fan Type Tubeaxial Noise 53.0 dB(A) Power (Watts) 12.60W RPM 3700 RPM Termination 2 Wire Leads Operating Temperature 14 ~ 140°F (-10 ~ 60°C) Approvals CE, CSA, UL, VDE Weight 0.564 lb (255.83g) Current Rating (Amps) 1.05A Voltage Range 4 ~ 13.2VDC Material - Frame Plastic Material - Blade Plastic Lifetime @ Temp. 70000 Hrs @ 40°C

Search Keywords: AFB1212SHE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB1212SHE
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
504
Category:
DC Fan
Dimension:
120 x 120 x 38 mm
Voltage Rating:
12 V
Power Rating:
12.6 W
Maximum Airflow:
151CFM
Noise Level:
53 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A

IN STOCK: 167

Ships today, if you order in

On Order: 504   can ship 1/26/26

MOQ for out of Stock Qty: 126

Factory Lead-Time 36 Weeks

Price (USD)

Qty
Unit Price
1
$20.003
25
$15.069
50
$13.689
100
$13.225
126
$13.163
252
$13.091
378
$13.030
504 +
$12.968
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
