AFB1224HHE-T500 by delta thermal / emi / solenoids
Image is representational - see mfr. specs

AFB1224HHE-T500

Delta Thermal / EMI / Solenoids

FAN 120x120x38mm 24VDC IP55 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AFB1224HHE-T500 is a DC brushless axial flow fan engineered for reliable thermal management applications. It features a two-phase four-pole motor with a rated voltage of 24 VDC, operating range of 7.0 to 27.6 VDC, and maximum input current of 0.45 A at 10.80 W maximum power consumption. The fan delivers a maximum air flow of 3.400 m³/min (120.07 CFM) at zero static pressure and maximum air pressure of 9.00 mmHg (0.354 inchH2O) at zero airflow, operating at 2900±10% RPM with acoustic noise averaging 44.0 dB-A. The unit incorporates a plastic frame and impeller (UL 94V-0), dual ball bearing system, and IP55 ingress protection rating, with a rated life expectancy of 70,000 hours continuous operation at 40°C. This fan is ideal for cooling applications in industrial equipment, telecommunications systems, and server environments where compact size, low noise, and long-term reliability are essential.

Search Keywords: AFB1224HHET500

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB1224HHE-T500
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
36

IN STOCK: 123

Can Ship immediately

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
1
$18.22
5
$17.59
10
$17.18
36
$16.91
72
$16.55
252
$16.02
504 +
$15.91
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
