EFC0812DB-F00 by delta thermal / emi / solenoids

EFC0812DB-F00

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 80x15mm - 12VDC - 48.8CFM - 3.96W - 0.33A - 41dBA - 3800RPM - Ball Bearing - PWM ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The EFC0812DB-F00 is a DC Axial Fan Voltage - Rated 12VDC Size / Dimension Square - 80mm L x 80mm H Width 15.00mm Air Flow 48.8 CFM (1.37m³/min) Static Pressure 0.171 in H2O (42.6 Pa) Bearing Type Ball Fan Type Tubeaxial Features PWM Control, Speed Sensor (Tach) Noise 41.0 dB(A) Power (Watts) 3.96W RPM 3800 RPM Termination 4 Wire Leads Operating Temperature 14 ~ 140°F (-10 ~ 60°C) Approvals CE, CSA, UL, VDE Weight 0.148 lb (67.13g) Current Rating (Amps) 0.330A Voltage Range 7 ~ 12.6VDC Material - Frame Aluminum Material - Blade Plastic Lifetime @ Temp. 70000 Hrs @ 40°C

Search Keywords: EFC0812DBF00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
EFC0812DB-F00
RoHS:
Yes
HTS:
8414596090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
504
Category:
DC Fan
Dimension:
80 x 80 x 15 mm
Voltage Rating:
12 V
Power Rating:
6 W
Maximum Airflow:
48.8 CFM
Noise Level:
45 dB
Tachometer Signal:
Yes
Special Features:
Tachometer Output
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 60 °C

IN STOCK: 0

On Order: 1,512   can ship 2/2/26
On Order: 1,465   can ship 3/2/26

Minimum Order: 5

Factory Lead-Time 80 Weeks

Price (CAD)

Qty
Unit Price
5
$26.216
25
$19.187
50
$16.859
100
$16.171
250
$15.481
504
$15.405
1,008 +
$15.328
Suppliers Standard Package
