FFB0412VHN-F00 by delta thermal / emi / solenoids
Image is representational - see manufacturer specifications
Delta Thermal / EMI / Solenoids Authorized Distributor

FFB0412VHN-F00

DC Fans DC Axial Fan - 40x28mm - 12VDC ...

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Delta Electronics FFB DC Axial Fans are built for high performance and feature a dual blade as well as a high air flow rotating stator blade. Delta FFB standard DC axial fan series has a plastic impeller and frame, as well as Delta’s maintenance-free ball bearing system. FEATURES Bearing type - ball bearing Impeller and frame material - plastic (UL 94V-0) Lead wires UL 1007 AWG #24 or equivalent Red wire positive (+) Black wire negative (-) Voltage - Rated 12VDC Size / Dimension Square - 40mm L x 40mm H Width 28.00mm Air Flow 15.8 CFM (0.442m³/min) Bearing Type Ball Fan Type Tubeaxial Features Speed Sensor (Tach) Noise 45.0 dB(A) Power (Watts) 1.92W RPM 9500 RPM Termination 3 Wire Leads

Search Keywords: FFB0412VHNF00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
FFB0412VHN-F00
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
288
Package Type:
Box
Category:
DC Fan
Dimension:
40 x 40 x 28 mm
Voltage Rating:
12 V
Power Rating:
1.92 W
Maximum Airflow:
15.7CFM
Noise Level:
45 dB
Tachometer Signal:
Yes
Special Features:
Tachometer Output
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

IN STOCK: 450

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
5
$14.99
25
$12.09
50
$11.18
100
$10.33
288
$9.92
576
$9.89
1,152 +
$9.87
Supplier's Standard Package
