507-4760-3331-500F by dialight
Image is representational - see mfr. specs

507-4760-3331-500F

Dialight

14V DC RED SHORT CYLINDRICAL LED INDICATOR ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

507-4760-3331-500F is a red LED indicator lamp cartridge designed for 14 VDC operation with a cylindrical lens configuration. The device features an aluminum housing with a plastic lens containing an internal Fresnel ring pattern to maximize light output. The lamp has a cylindrical lens design (FIG. 1) with an outer diameter of 0.330 inches (8.38 mm) and a pin diameter of 0.040 inches (1.02 mm), with an overall height of 0.90 inches (22.86 mm). The product is RoHS compliant and can be integrated with Dialight 250 and 508 series holders for 0.375-inch mounting holes or 515 series connectors for 9/32-inch mounting holes. This lamp is suitable for panel-mount indicator applications in industrial control systems, instrumentation, and signaling equipment where reliable visual feedback is required.

Search Keywords: 50747603331500F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
507-4760-3331-500F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541402000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
BAG
Mounting:
Through Hole
Dimension:
23.8 x 8.38 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
14(Typ) V
Color:
Red
Peak Wavelength:
N/A
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
8.38x8.38x6.73 mm
Intensity:
10 mcd
Viewing Angle:
N/A
Maximum Forward Current:
20(Typ) mA

IN STOCK: 25

Ships today, if you order in

On Order: 160   can ship 10/1/26

Minimum Order Quantity: 5

Multiple: 5

Factory Lead-Time 27 Weeks

Price (USD)

Qty
Unit Price
5
$6.30
50
$5.13
100
$4.89
250
$4.69
500
$4.49
1,000
$4.38
2,500
$4.26
5,000 +
$4.20
Suppliers Standard Package
