559-5201-007F by dialight
Image is representational - see manufacturer specifications
Dialight Authorized Distributor

559-5201-007F

559 LED PMI 0.250" Green, Tintd, Diff, 2.2 VDC, 14" Wire Leads, 24 AWG, Ext Resist Req ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 559-5201-007F is a snap-in LED panel mount indicator from Dialight's 559 series, featuring a green LED with a peak wavelength of 569 nm and typical intensity of 40 mcd. This indicator operates at 10 mA forward current with a forward voltage of 2.1 VDC and supports a 50° viewing angle, making it suitable for applications requiring reliable visual feedback. The device accommodates a 0.250" (6.35 mm) mounting hole with a maximum panel thickness of 0.031" to 0.062" (0.787 to 1.57 mm), and operates across a wide temperature range from -55°C to +100°C. It is available with straight terminals for wire wrapping or 24 AWG lead wire in 6" or 14" lengths, and features a black UL94V-0 flammable housing with RoHS compliance. Common applications include fan tray assemblies, data-center infrastructure, wireless infrastructure, electronic test and measurement instruments, and communications testing equipment.

Search Keywords: 5595201007F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
559-5201-007F
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541402000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
BAG
Mounting:
Panel
Dimension:
15.88(Max) x 7.14 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
2.2(Typ) V
Color:
Green
Peak Wavelength:
563 nm
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
34 mcd
Viewing Angle:
50 °
Maximum Forward Current:
25 mA

IN STOCK: 1,128

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
50
$2.06
300
$1.95
500
$1.77
1,000
$1.69
2,500
$1.68
5,000
$1.66
7,500
$1.65
10,000 +
$1.64
