607-2312-130F by dialight
Image is representational - see manufacturer specifications
Dialight Authorized Distributor

607-2312-130F

607 LED PMI 0.283" Yellow, Recessed, 12 VDC, Straight Leads, Chrome ...

View Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

607-2312-130F is a 7mm recessed panel mount LED indicator designed for status indication, power indication, and maintenance warning applications. The indicator features a yellow LED with a typical intensity of 70 mcd and operates at 12 VDC without requiring an external resistor. It is housed in a brass-chrome plated body with copper-nickel plated terminals and a non-polarized configuration, mounted through a 0.283" (7.2 mm) hole with a maximum panel thickness of 0.336" (8.50 mm). The device operates reliably across a temperature range of -25°C to +85°C for both operating and storage conditions, and is RoHS compliant with NEMA 4X and IP66 ratings for watertight applications. This indicator is ideal for instrumentation, remote power indication, and industrial control systems requiring durable, visible status feedback.

Search Keywords: 6072312130F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
607-2312-130F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536610000
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
BAG
Mounting:
Panel
Dimension:
27.69 x 8.38 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
N/A
Color:
Yellow
Peak Wavelength:
N/A
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
66 mcd
Viewing Angle:
N/A
Maximum Forward Current:
N/A

IN STOCK: 464

Can Ship immediately

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
25
$4.81
50
$4.80
100
$4.00
250
$3.97
500
$3.94
1,000
$3.93
2,500
$3.92
5,000 +
$3.91
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
