KBPC5006FP by diotec semiconductors
Image is representational - see manufacturer specifications
Diotec Semiconductors Authorized Distributor

KBPC5006FP

Bridge - 1-ph - KBPC - 600V - 50A - 150°C ...

View Datasheet
RoHS Compliant
Bulk Packaging
Accessories
Certificate of Compliance

DESCRIPTION

KBPC5006FP is a single-phase diode bridge rectifier designed for 50/60 Hz mains rectification and power supply applications. It features four diodes in bridge configuration with a maximum rectified output current of 50 A at forced cooling (Tc = 50°C), a repetitive peak reverse voltage (VRRM) of 600 V, and a forward voltage drop of less than 1.1 V at 25 A. The device operates over a junction temperature range of -50°C to +150°C and includes a plastic case with isolated aluminum baseplate for thermal management. With fast-on terminals (FP designation), peak forward surge current capability of 400 A (50 Hz, 10 ms) or 450 A (60 Hz, 8.3 ms), and reverse recovery time of approximately 1500 ns, this rectifier is well-suited for commercial and industrial-grade power conversion applications requiring reliable high-voltage rectification.

Search Keywords: KBPC5006FP

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Diotec Semiconductors
Part No:
KBPC5006FP
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85411000
COO:
IN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
240
Package Type:
Bulk

IN STOCK: 315

Can Ship immediately

Manufacturer Stock: 1,440   can ship 9/7/26

Minimum Order Quantity: 10

Factory Lead-Time 5 Weeks can ship 9/28/26

Price (USD)

Qty
Unit Price
10
$3.44
240
$2.35
480
$2.34
720
$2.08
1,200
$2.07
2,640
$2.06
5,040
$2.05
7,680 +
$2.04
Supplier's Standard Package
