3003P1J1M7QE by e-switch

3003P1J1M7QE

E-Switch

Rocker Switch - 3PDT - On-None-On - 120VAC/28VDC - 5A - Silver Plated Contacts - PC Mount - Vertical Right Angle PC Pins - Black Actuator ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The E-SWITCH 3003P1J1M7QE is a high-quality rocker switch designed for various electrical applications. This 3PDT (3 Pole Double Throw) switch features an On-None-On configuration, allowing for versatile control options. It can handle a voltage of 120VAC or 28VDC, making it suitable for a range of circuit requirements. With a 5A current rating, this switch ensures reliable and efficient operation. The silver-plated contacts deliver superior conductivity and durability. To facilitate easy installation, it comes with PC mount and vertical right angle PC pins. The black actuator provides a sleek and stylish appearance while offering smooth and comfortable operation.

Search Keywords: 3003P1J1M7QE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
3003P1J1M7QE
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
54
Mounting:
Bracket Mount/Through Hole
Pole Throw Configuration:
3P2T (3PDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Rocker
Actuator Color:
Black
Bezel Color:
N/R
Illumination:
N/R
Terminal Type:
PC Pins
Body Orientation:
Vertical Right Angle

IN STOCK: 0

MOQ for out of Stock Qty: 68

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
68
$14.245
135
$8.837
203
$6.973
270 +
$6.839
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
