320.02E11.08BLK by e-switch
Image is representational - see mfr. specs

320.02E11.08BLK

E-Switch

Tactile Switch - SPST NO - 50VDC - 25mA - 135 (+/-) 50 gf - Black Button - Through Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 320.02E11.08BLK is a tactile pushbutton switch featuring a single-pole single-throw (SPST) circuit configuration with a black cap. It is designed for PCB mounting with a 2.54 mm pitch and utilizes an E1-1 contact dome for reliable switching performance. The switch has a contact rating of 25 mA at 50 VDC, an operating force of 135 ± 50 gf, and a travel distance of 0.7 mm, ensuring responsive tactile feedback. With its compact dimensions (14.4 mm height, 7.50 mm width, 4.00 mm depth) and standard PCB layout, this switch is ideal for consumer electronics, industrial control panels, and embedded systems requiring reliable momentary switching functionality.

Search Keywords: 32002E1108BLK

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
320.02E11.08BLK
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
162
Dimension:
12.4 x 12.4 x 14.4 mm
Mounting:
Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
On Off
Actuator Style:
Round Button
Contact Rating @ Voltage:
0.025A@50 VDC
Body Orientation:
Straight
Seal Location:
N/A

IN STOCK: 1,949

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
10
$2.71
162
$2.33
324
$2.24
648
$2.13
1,134
$2.06
2,592
$1.95
5,022
$1.64
7,614 +
$1.59
Suppliers Standard Package
