KAE04LGGT by e-switch
Image is representational - see mfr. specs

KAE04LGGT

E-Switch

Low Profile DIP Switch - 25mA@24VDC - 4 Position - SPST - Extended Actuator - 2000 cycles - Tube ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

KAE04LGGT is a 4-position DIP switch designed for PCB mounting with gold-plated copper movable contacts and brass terminals. The switch features a contact rating of 25 mA at 24 VDC for switching and 100 mA at 50 VDC for carry operations, with a maximum contact resistance of 50 mO initial and an insulation resistance of 100 MO minimum at 500 VDC. It operates reliably over a temperature range of -20°C to +85°C with a storage temperature range of -40°C to +85°C, and provides 2000 electrical life cycles with a dielectric strength of 500 VAC minimum for 1 minute. The switch features a travel distance of 1.00 mm and an operating force of 1000 grams maximum, making it suitable for industrial control panels, consumer electronics, and embedded systems requiring reliable configuration switching.

Search Keywords: KAE04LGGT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
KAE04LGGT
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8537109170
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
42
Package Type:
Tube
Body Orientation:
Straight
Actuator Style:
Raised Slide
Actuator Length:
0.7 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.025@24VDC A
Contact Plating:
N/A
Terminal Pitch:
2.54 mm

IN STOCK: 756

Can Ship immediately

Minimum Order Quantity: 42

Multiple: 42

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
42
$1.244
252
$1.072
504
$1.009
1,008
$0.957
2,520
$0.891
5,040
$0.851
7,518
$0.847
10,038 +
$0.843
