MS0850500F080S1A by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

MS0850500F080S1A

Switch - SPDT - 5A - 125VAC - Round (Pin Plunger) Actuator - 80gf Operating Force - Solder Lug - Chassis Mount.

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MS0850500F080S1A is switch typically used for: appliance, timing controls, vending machines, gaming, industrial controls and power tools. Operating temperature range is from -25°C to 85°C.

Search Keywords: MS0850500F080S1A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
MS0850500F080S1A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
270
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
High Temperature Polybutylene Terephthalate/Button
Contact Rating @ Voltage:
5@250VAC@(cUL/UL/VDE) A
Maximum Movement Differential:
N/A
Operating Force:
0.78 N
Termination Style:
Solder
Dimension:
19.8 x 6.4 x 16 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 2,035

Ships today, if you order in

Minimum Order Quantity: 270

Multiple: 270

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
270
$0.972
540
$0.919
1,080
$0.862
2,700
$0.857
5,130
$0.754
7,560
$0.752
10,260
$0.751
15,120 +
$0.749
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
