R5ABLKBLKFF0 by e-switch
Image is representational - see mfr. specs

R5ABLKBLKFF0

E-Switch

Switch Rocker ON OFF DPST Quick Connect Curved Rocker 20A 250VAC 250VDC 559.27VA 30000Cycles ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The R5ABLKBLKFF0 is a DPST on-off rocker switch manufactured by E-SWITCH, featuring a black actuator, white graphics, and black housing for panel-mount applications. This switch is rated for 20A at 125VAC (3/4 HP) and 16A at 250VAC (1 HP) with UL approval, providing reliable switching performance across standard AC voltage levels. The switch operates over a terminal-side temperature range of -20°C to 85°C and rocker-side range of -20°C to 55°C, with an electrical life of 10,000 cycles and mechanical life of 30,000 cycles. Key electrical characteristics include contact resistance below 20 milli-ohms, dielectric strength exceeding 1,500V AC, and insulation resistance greater than 1,000 megohms. This switch is ideal for industrial control panels, appliances, and equipment requiring robust on-off switching with high reliability and long operational life.

Search Keywords: R5ABLKBLKFF0

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
R5ABLKBLKFF0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
75
Mounting:
Panel Mount
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
559.27 A
Actuator Style:
Curved Rocker
Actuator Color:
Black
Bezel Color:
Black
Illumination:
N/R
Terminal Type:
Quick Connect
Body Orientation:
Straight

IN STOCK: 1,025

Can Ship immediately

Minimum Order Quantity: 75

Multiple: 75

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
75
$1.62
150
$1.55
300
$1.46
525
$1.40
1,050
$1.34
2,550 +
$1.33
