R726FB1-SXXXNBBNNX by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

R726FB1-SXXXNBBNNX

Switch Rocker (ON) OFF (ON) DPDT Quick Connect Rocker 20A 250VAC ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The R726FB1-SXXXNBBNNX is a DPDT (double-pole double-throw) pushbutton switch featuring a three-position momentary/maintained action configuration with positions for ON-OFF-ON operation. The switch is rated for 20A at 125/250VAC at 50/60 Hz with a contact resistance of less than 20 milliohms initial, ensuring reliable electrical performance. It offers a dielectric strength greater than 1,500V AC for 1 minute and insulation resistance exceeding 100 megohms at 500VDC, with an operating temperature range of 0°C to 55°C. The switch features a black TPR rubber actuator and bezel, includes a rubber gasket, and is UL listed and RoHS compliant. With an electrical life of 10,000 cycles and mechanical life of 30,000 cycles, this switch is suitable for industrial control panels, machinery, and equipment requiring robust switching functionality.

Search Keywords: R726FB1SXXXNBBNNX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
R726FB1-SXXXNBBNNX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Mounting:
Panel Mount
Pole Throw Configuration:
DPDT
Switch Configuration:
(On) Off (On)
Contact Rating @ Voltage:
20@250VAC A
Actuator Style:
Rocker
Actuator Color:
Black
Bezel Color:
N/A
Illumination:
N/R
Terminal Type:
Quick Connect
Body Orientation:
Straight

IN STOCK: 409

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$13.42
30
$11.63
60
$10.99
120
$10.45
270
$9.90
510
$9.54
1,020 +
$9.52
