TL3301NF160QJ by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

TL3301NF160QJ

Tactile Switch - SPST-NO - 50mA@12VDC - 4.3mm Actuator - 160gf - SMD J-Lead - Silver Plated Contacts - -40°C to 85°C ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TL3301NF160QJ is a single-pole single-throw (SPST) tactile pushbutton switch designed for reliable switching applications. It features a 160 ± 50 gf operating force with a travel distance of 0.25 mm (+0.2/-0.1 mm), silver contact material, and a maximum initial contact resistance of 100 mO. The switch is rated for 12VDC at 50mA and operates reliably across a temperature range of -40°C to +85°C, with a mechanical and electrical life rating of 100,000 cycles minimum. This switch is ideal for consumer electronics, industrial control panels, and portable devices requiring durable tactile feedback and long-term reliability.

Search Keywords: TL3301NF160QJ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
TL3301NF160QJ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1100
Package Type:
REEL
Dimension:
6mm x 6.6mm x 4.6 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Round Button
Operating Force:
1.57 N
Contact Rating @ Voltage:
0.05@12VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
J-Lead
Seal:
N/A
Seal Location:
N/A

IN STOCK: 0

Minimum Order Quantity: 1100

Multiple: 1100

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1,100
$0.2153
3,300
$0.2060
5,500
$0.2055
7,700
$0.2050
11,000
$0.2045
25,300
$0.2039
50,600 +
$0.2034
Reel Package
