4230-T110-K0BE-16A by e-t-a engineering technology
Image is representational - see manufacturer specifications
E-T-A Engineering Technology Authorized Distributor

4230-T110-K0BE-16A

Thermal-magnetic Circuit Breaker - DIN Mount - 16A - 1 Pole - Screw Terminals - IEC/EN 60947-2(TÜV)/UL1077 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 4230-T110-K0BE-16A is a single-pole thermal-magnetic miniature circuit breaker designed for DIN rail mounting with toggle actuation and visual status indication. It features a rated current of 16 A, screw terminals with a maximum tightening torque of 2 Nm, and supports cable cross-sections up to 35 mm². The device operates across an ambient temperature range of -35°C to +70°C and provides insulation coordination at overvoltage category III (Uimp 4 kV) with pollution degree 3 protection. It complies with IEC/EN 60947-2 and UL 1077 standards, offering a positively trip-free snap action mechanism for reliable switching behavior. Typical applications include protection of cables, motors, generators, transformers, and industrial control systems, with a typical operational life of 20,000 cycles.

Search Keywords: 4230T110K0BE16A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-T-A Engineering Technology
Part No:
4230-T110-K0BE-16A
Unit of Measure:
Per Each
RoHS:
Yes
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Type:
Thermal2867
Voltage Rating:
2772868VAC,802868VDC
Number of Poles:
12860
Current Rating:
16 A
Terminal Design:
Screw2865
Operating Temperature:
-35 to 70 °C
Mounting:
DIN Rail2859

IN STOCK: 50

Can Ship immediately

Manufacturer Stock: 140   can ship 8/28/26

Minimum Order Quantity: 5

Factory Lead-Time 2 Weeks can ship 8/27/26

Price (USD)

Qty
Unit Price
5
$11.04
25
$10.34
50
$10.04
100
$9.74
250
$9.34
500
$9.04
1,000 +
$8.74
