4230-T110-K0CE-20A by e-t-a engineering technology
Image is representational - see mfr. specs

4230-T110-K0CE-20A

E-T-A Engineering Technology

Thermal-magnetic Circuit Breaker - DIN Mount - 20A - 1 Pole - Screw Terminals - IEC/EN 60947-2(TÜV)/UL1077 ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 4230-T110-K0CE-20A is a single-pole thermal-magnetic miniature circuit breaker designed for DIN rail mounting with toggle actuation and visual status indication. It features a positively trip-free snap action mechanism for reliable switching behavior, rated at 20 A for AC 240 V operation in accordance with EN 60947-2 and UL 1077 standards. The device incorporates screw terminals with a maximum tightening torque of 2 Nm, cable cross-section capability up to 35 mm², and operates reliably across an ambient temperature range of -35°C to +70°C. With an insulation coordination of overvoltage category III (Uimp 4 kV) and IP20 degree of protection, this circuit breaker is ideal for protecting cables, motors, generators, transformers, and industrial control systems. The device provides approximately 20,000 cycles of typical life and weighs approximately 116 g per pole.

Search Keywords: 4230T110K0CE20A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-T-A Engineering Technology
Part No:
4230-T110-K0CE-20A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Type:
Thermal Magnetic2867
Voltage Rating:
2402868VAC,802868VDC
Number of Poles:
12860
Current Rating:
20 A
Terminal Design:
Screw2865
Operating Temperature:
-30 to 75 °C
Mounting:
DIN Rail2859

IN STOCK: 174

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
5
$18.82
25
$15.05
50
$12.21
100
$11.25
250
$9.91
500
$9.38
1,000 +
$9.01
Log in for special pricing Click for Quote Price Match Request
