BK/AGC-10-R by eaton electronics / bussmann
Image is representational - see manufacturer specifications
Eaton Electronics / Bussmann Authorized Distributor

BK/AGC-10-R

The BK/AGC-10-R is a fast-acting, 10A, 250V glass tube fuse in a 1/4" x 1-1/4" package designed for overcurrent protection. ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The BK/AGC-10-R is a fast-acting cartridge fuse from the AGC series, providing reliable overcurrent protection. It is rated for 10A and 250V, with an AC interrupting capacity of 200A at 250V and 10,000A at 125V. This fuse features a glass tube with nickel-plated brass endcaps, a typical DC cold resistance of 0.008 ohms, and a typical melting I²t of 0.492 A²Sec. As a UL Listed and RoHS compliant component, it is well-suited for a wide range of applications including consumer electronics and industrial equipment.

Search Keywords: BKAGC10R

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Eaton Electronics / Bussmann
Part No:
BK/AGC-10-R
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536100020
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
OTHER
Type:
Miniature
Fuse Size:
6.3 x 32 mm
Acting:
Fast
Current Rating:
10 A
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
N/A
Fuse Material:
Glass
Mounting:
Holder
  Different packaging options available.  See Alternatives

IN STOCK: 7,509

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
100
$0.905
300
$0.734
500
$0.733
1,000
$0.702
2,500
$0.645
5,000
$0.644
7,500
$0.627
10,000 +
$0.626
