FPT705-200-R by eaton electronics / bussmann
Image is representational - see manufacturer specifications
Eaton Electronics / Bussmann Authorized Distributor

FPT705-200-R

Inductor Power Wirewound 0.2uH/0.18uH 10% 1MHz Ferrite 13A 0.00065Ohm DCR T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

FPT705-200-R is a dual conductor, high current power inductor designed for applications requiring compact, magnetically shielded inductance. It features a two-turn construction with ferrite core material, providing an open circuit inductance of 200 nH (±10%) and a DC resistance of 0.65 mO at +20°C. The inductor supports an RMS current of 13 A and a saturation current of 25 A, housed in an 8.3 mm x 7.5 mm surface mount package with a maximum height of 5.35 mm. Operating temperature range spans -55°C to +125°C, and the component is RoHS compliant and halogen-free. This inductor is compatible with Pico power modules and is ideal for high-efficiency power conversion applications.

Search Keywords: FPT705200R

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Eaton Electronics / Bussmann
Part No:
FPT705-200-R
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
PH
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
REEL

IN STOCK: 7,451

Can Ship immediately

Minimum Order Quantity: 250

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
250
$1.587
500
$1.522
1,000
$1.457
3,000
$1.353
5,000
$1.306
8,000
$1.262
10,000
$1.224
15,000 +
$0.938
Reel Package
Log in for special pricing Click for Quote Price Match Request
