S505-2-R by eaton electronics / bussmann
Image is representational - see manufacturer specifications
Eaton Electronics / Bussmann Authorized Distributor

S505-2-R

The S505-2-R is a 2A, 250V time-delay ceramic tube fuse in a 5mm x 20mm package for overcurrent protection. ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The S505-2-R is a time-delay, high breaking capacity fuse featuring a ceramic tube construction. It has a current rating of 2A, a voltage rating of 250V AC, and a high interrupting rating of 1500A. Key electrical characteristics include a typical DC cold resistance of 0.041 ohms, a typical melting I²t of 7.6 A²Sec, and a typical voltage drop of 110 mV at its rated current. As a RoHS compliant component designed to IEC 60127-2, this 5mm x 20mm fuse is ideal for providing overcurrent protection in a wide variety of electronic circuits.

Search Keywords: S5052R

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Eaton Electronics / Bussmann
Part No:
S505-2-R
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536100040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
5
Package Type:
OTHER
Type:
Miniature
Fuse Size:
5 x 20 mm
Acting:
Slow Blow
Current Rating:
2 A
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
N/A
Fuse Material:
Ceramic
Mounting:
Holder
  Different packaging options available.  See Alternatives

IN STOCK: 40

Can Ship immediately

Minimum Order Quantity: 5

Multiple: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$9.19
50
$5.31
100
$4.95
250
$4.69
500
$4.66
1,000
$4.65
2,500
$4.64
5,000 +
$4.62
