3414N/39HH by ebm-papst
Image is representational - see manufacturer specifications
ebm-papst Authorized Distributor

3414N/39HH

Fan Tubeaxial - 24VDC - Square - 92mm L x 92mm H - Ball - 60.0 CFM (1.68m³/min) - 3250 RPM - 38.0 dB(A) - 3 Wire Leads.

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3414N/39HH is tubeaxial fan with polyamide (PA), nylon, fiberglass reinforced blade and polybutylene terephthalate (PBT), fiberglass reinforced frame. Operating temperature range is from -4 to 158°F (-20 to 70°C).

Search Keywords: 3414N39HH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ebm-papst
Part No:
3414N/39HH
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596090
COO:
EU
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
27
Package Type:
Box
Category:
DC Fan
Dimension:
92 x 92 x 25.4 mm
Voltage Rating:
24 V
Power Rating:
3.1 W
Maximum Airflow:
60 CFM
Noise Level:
39 dB
Rotation Detect Signal Signal:
Yes
Special Features:
Speed/Rotation/Rotor-Lock Alarm
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-20 to 70 °C

IN STOCK: 6

Ships today, if you order in

On Order: 162   can ship 11/6/26

MOQ for out of Stock Qty: 7

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$51.38
5
$48.66
7
$43.06
14
$37.58
21
$37.49
27 +
$33.78
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

LZ23-3

Thrml Mgmt Access Finger Guard Black Plastic

LZ261

Thrml Mgmt Access Fiberglass Spacer

LZ23-2

Thrml Mgmt Access Finger Guard 92mm Plastic

LZ370

Temperature Sensor for use with VARIOFAN series.

LZ23

Fan Accessories Metal Finger Guard for 92mm Size Fans or Series 3300/3300V/3400/3400N/3400 ...

Show 3 More
