6318/2TDH4P by ebm-papst

6318/2TDH4P

ebm-papst

DC Fan Axial Ball Bearing - 48V - 36V to 72V - 559.1CFM - 75dB Low Noise/PWM - 9200RPM. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 6318/2TDH4P is a 48VDC Axial Fan with a ball bearing and glass-fiber reinforced PA plastic impeller. This high performance DC fan features die-cast aluminum housing, electrical connection is via TR 64 18/20/22AWG speed signal and control input cable. The motor is protected against reverse polarity and blocked rotor. The rotational direction is counter clock wise direction looking towards rotor and the air exhaust over struts. 3-phase fan drive with very smooth operation and high efficiency housing with grounding lug for M4 x 8 screw (Torx) power consumption when wide open; these values may be considerably higher at the operating point.

Search Keywords: 63182TDH4P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ebm-papst
Part No:
6318/2TDH4P
RoHS:
Yes
HTS:
8414596590
COO:
HU
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Category:
DC Fan
Dimension:
171.5mm dia x 50.8 mm
Voltage Rating:
48 V
Power Rating:
150 W
Maximum Airflow:
559CFM
Noise Level:
75 dB
Tachometer Signal:
Yes
PWM Control Signal:
Yes
Special Features:
Tachometer Output, External Temperature Sensor, PWM speed control
Termination:
Lead Wires
Housing Material:
Die-Cast Aluminum
Operating Temperature:
-20 to 75 °C

IN STOCK: 217

Ships today, if you order in

On Order: 250   can ship 12/19/25

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1
$196.792
3
$193.722
5
$188.933
10 +
$160.289
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
