6424H by ebm-papst
Image is representational - see mfr. specs

6424H

ebm-papst

DC Fan Axial Ball Bearing 24V 12V to 28V 282.5CFM 63dB ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 6424H is a 24VDC high speed Axial Fan with speed signal, housing with earthing lug for bolt M4 x 8 (Torx) free air power consumption, ball bearing and terminal power connection. Die-cast aluminium housing and fibreglass-reinforced plastic (PA) impeller. Left direction of rotation looking at rotor, air exhaust over bars direction of air flow, flat plugs of 3 x 0.5mm connection. The DC axial compact fan is suitable for high air performance with moderate pressure build-up. The flow of air through the fan blades is parallel to the rotation axis. 4000RPM Speed rating 26W Rated power -20 to 55°C Maximum ambient temperature range Electronic blocking protection, motor current limit in the start-up phase and when rotor is blocked Protected against reverse polarity and locking

Search Keywords: 6424H

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ebm-papst
Part No:
6424H
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596090
COO:
HU
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Category:
DC Fan
Dimension:
171.5 x 150 x 50.8 mm
Voltage Rating:
24 V
Power Rating:
26 W
Maximum Airflow:
282CFM
Noise Level:
63 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Aluminum
Operating Temperature:
-20 to 55 °C

IN STOCK: 23

Ships today, if you order in

On Order: 75   can ship 6/15/26
On Order: 75   can ship 7/10/26

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$140.11
5
$129.66
10
$124.10
20
$119.00
50
$115.82
100 +
$114.30
