8312 by ebm-papst
Image is representational - see manufacturer specifications
ebm-papst Authorized Distributor

8312

DC Fans DC Tubeaxial Fan, 80x80x32mm, 12VDC, 31.8CFM, 2.6W, 36dBA, 3300RPM, Ball Bearing ...

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
End of Life: Final orders must be placed by 12/11/2026
Certificate of Compliance

DESCRIPTION

The 8312 is a 12VDC Axial Fan with speed signal, Go/No-go alarm and alarm with limit speed. This fan comes with an external temperature sensor, internal temperature sensor, PWM control input and analogue control input. It features moisture protection, protection against salt spray and fog protection. Ball bearing and wire leaded power connection. Fibreglass-reinforced plastic (PBT) housing and fibreglass-reinforced plastic (PA) impeller. Right direction of rotation looking at rotor, air exhaust over bars direction of air flow, single strands 22AWG, TR 64, bared and tin-plated leads. The DC axial compact fan is suitable for high air performance with moderate pressure build-up. The flow of air through the fan blades is parallel to the rotation axis.

Search Keywords: 8312

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ebm-papst
Part No:
8312
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596090
COO:
HU
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Category:
DC Fan
Dimension:
80 x 80 x 32 mm
Voltage Rating:
12 V
Power Rating:
2.6 W
Maximum Airflow:
31.8 CFM
Noise Level:
36 dB
Special Features:
None
Termination:
Terminals
Housing Material:
Plastic
Operating Temperature:
-20 to 75 °C
End of Life:
Final orders must be placed by 12/11/2026
  End of Life: Final orders must be placed by 12/11/2026

IN STOCK: 0

On Order: 210   can ship 10/12/26

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1
$61.75
5
$61.04
10
$60.44
25
$59.37
50
$54.43
100
$52.88
250 +
$52.75
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes

Accessories

LZ212

Thrml Mgmt Access Fan Clip Steel

LZ370

Temperature Sensor for use with VARIOFAN series.

LZ22N

Fan Accessories Guard Grille for 80mm Size Fans or 8000 Series - 5-Ring.

LZ260

Thrml Mgmt Access Fiberglass Spacer Plastic

LZ60-8

Thrml Mgmt Access Finger Guard 80mm Metal

Show 3 More
