342-026-541-202

EDAC

Card Edge Connector - 26 Contacts - 0.100” (2.54mm) Pitch - Dual Row - 0.062” (1.57mm) Thick PCB - Board Mount

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

342 Series (.100" (2.54mm) contact spacing) Card Edge Connector with 26 Wire Wrap contacts. The tails are .025"Sq' (0.64mm Sq') and .760" (19.30mm) long in a Double Row formation. The Insulator is Green in color with Ø.128" (Ø3.25mm) Mounting Holes .

Search Keywords: 342026541202

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
EDAC
Part No:
342-026-541-202
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Type:
Card Edge
Body Orientation:
Straight
Mounting:
Through Hole
Termination Method:
Wire Wrap
Card Thickness:
1.57 mm
Pitch:
2.54 mm
Number of Contacts:
26
Operating Temperature:
-65 to 105 °C

IN STOCK: 75

Ships today, if you order in

Minimum Order: 25

Multiple: 25

Factory Lead-Time 6 Weeks

Price (CAD)

Qty
Unit Price
25
$12.668
50
$11.862
100
$11.180
250
$10.828
500
$9.647
1,000
$7.258
2,500
$6.830
5,000 +
$6.524
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
