D4G0303S by electroswitch electronic products
Image is representational - see manufacturer specifications

D4G0303S

Open Frame Rotary Switch - 3 Pole - 2 to 3 Position Adjustable - Shorting - 1.5A@28VDC/0.5A@115VAC - Glass Epoxy - Solder Terminals ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

D4G0303S is a 3-pole rotary switch with 2-3 active positions, featuring glass epoxy insulation and solder lug terminals with adjustable stops. The switch employs a single-ball, hill and valley indexing mechanism with a positive 30° index angle and has a minimum index life of 25,000 cycles. It is rated for 1.5 amps at 28 VDC (make and break resistive load) with a current carrying capacity of 9 amps, dielectric strength of 1,500 VAC, and average initial contact resistance of 3.5 milliohms. The switch features non-corrosive brass clips and rotors with silver plate finish, adjustable index stops with a minimum stop strength of 10 in. lbs., and is housed in a 1.437" diameter package with solder lug terminals. This economical and versatile switch is ideal for applications requiring reliable multi-position switching in industrial control systems, instrumentation, and electronic equipment.

Search Keywords: D4G0303S

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Electroswitch Electronic Products
Part No:
D4G0303S
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Number of Positions:
3
Pole Throw Configuration:
3P3T
Actuator Length:
47.6 mm
Actuator Style/Diameter:
Round Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
1.5@28VDC A

IN STOCK: 98

Can Ship immediately

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$34.07
5
$32.12
10
$31.63
25
$31.17
50
$24.32
100
$18.67
250 +
$18.44
