A226P32YZQ by electroswitch
Image is representational - see mfr. specs

A226P32YZQ

Electroswitch

Switch Toggle ON None (ON) DPDT Flat Lever Solder Lug 6A 250VAC 28VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

A226P32YZQ is a miniature toggle switch designed for reliable switching in industrial and electronic control applications. It features a single-pole double-throw (SPDT) circuit with epoxy sealed terminals and gold/nickel/brass contacts, providing robust electrical performance. The switch is rated for 6 amperes at 125 VAC, 3 amperes at 250 VAC, or 6 amperes at 28 VDC resistive, with an initial contact resistance of 10 milliohms maximum at 3 VDC. It offers a life expectancy of 60,000 make-and-break cycles under resistive load and maintains an insulation resistance of 1,000 megohms minimum. The switch includes a nickel-plated brass bushing, stainless steel clamp frame, and tin-plated steel support brackets, with dielectric strength rated at 1,000 volts RMS at sea level. This configuration makes it suitable for panel-mount applications requiring reliable switching with compact dimensions and multiple lever options.

Search Keywords: A226P32YZQ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Electroswitch
Part No:
A226P32YZQ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None (On)
Contact Rating @ Voltage:
6@125VAC 28VDC A
Actuator Style:
Flat Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
12.7 x 11.43 x 33.17 mm
Operating Temperature:
N/A

IN STOCK: 37

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$29.18
5
$27.34
10
$26.53
25
$25.48
50
$20.13
100
$15.70
250 +
$15.02
