C4D0206S-A by electroswitch

C4D0206S-A

Electroswitch

Fully Enclosed Rotary Switch - 2 Pole - 2 to 6 Position Adjustable - Shorting - 0.5A@28VDC/0.3A@125VAC - Diallyl phthalat - 60° Index - Solder Terminals ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ELECTROSWITCH C4D0206S-A is a robust and reliable fully enclosed rotary switch designed for various applications. It features 2 poles and can be easily adjusted to 2 to 6 different positions. This particular model is a shorting switch, ensuring quick circuit interruption. The switch has a high current rating of 0.5A@28VDC and 0.3A@125VAC, making it suitable for a wide range of voltage requirements. Crafted from durable Diallyl phthalate material, it ensures long-lasting performance even in demanding environments. The switch operates with a smooth 60° index, allowing for precise and effortless adjustments. It is equipped with solder terminals for convenient and secure connections. Whether used in industrial, automotive, or electronic applications, the ELECTROSWITCH C4D0206S-A is an ideal choice for those seeking a high-quality and adjustable rotary switch.

Search Keywords: C4D0206SA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Electroswitch
Part No:
C4D0206S-A
RoHS:
Yes
HTS:
8536507000
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
6
Pole Throw Configuration:
DP6T
Actuator Length:
12.7 mm
Dimension:
38.1 x 38.1 x 42.34 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.5@28VDC A

IN STOCK: 80

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (CAD)

Qty
Unit Price
1
$57.577
5
$51.114
10
$44.561
25
$42.157
50
$41.943
100
$41.729
250 +
$41.529
