2643480102 by fair-rite products
Image is representational - see manufacturer specifications
Fair-Rite Products Authorized Distributor

2643480102

Ferrite Core Round Cable 43-Material ...

View Datasheet Ask the Datasheet
RoHS Compliant
CARTON Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 2643480102 is a round cable EMI suppression core manufactured by Fair-Rite Products, designed to reduce electromagnetic interference in cable applications. This ferrite core features material grade 43 with a burnished finish to remove sharp edges, and is characterized by typical impedance values of 64 O at 10 MHz, 92 O at 25 MHz, 127 O at 100 MHz, and 139 O at 250 MHz. The core has outer diameter A of 12.3 mm, inner diameter B of 4.95 mm, and length C of 12.7 mm, with a weight of 6 grams. The DC bias field is 0.52 Oe for 1 turn and 1 ampere, and the core length can be modified to suit specific applications. These suppression cores are ideal for signal integrity in high-frequency cable assemblies, telecommunications, and industrial equipment where EMI mitigation is critical.

Search Keywords: 2643480102

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Fair-Rite Products
Part No:
2643480102
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8547108000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1242
Package Type:
CARTON
Inductance Tolerance:
N/A
Typical Inductance:
N/A
Family:
2643480102
Operating Temperature:
-55 to 125 °C
Mounting:
Cable Mount5592
Core Material:
435587
Type:
Round Cable5597
Application:
Suppression Component5586
Dimension:
12.7 x 12.35594mm

IN STOCK: 0

Minimum Order Quantity: 50

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
50
$0.5242
500
$0.3063
1,242
$0.2511
3,726
$0.2487
6,210
$0.2481
8,694 +
$0.2475
