Image is representational - see mfr. specs

EZ-240-TM-X

Fairview Microwave

TNC Male (Plug) Connector For LMR-240 Cable, Crimp/Non-Solder Contact ...

Datasheet

RoHS Compliant

Bag Packaging

DESCRIPTION

The EZ-240-TM-X is a TNC male connector designed for LMR-240 cable applications with a captivated contact pin (EZ design) and crimp ferrule assembly. It features a 50O impedance with a frequency range of 0–6 GHz, supporting a voltage rating of 500V (rms) and dielectric withstanding voltage of 750V. The connector exhibits excellent electrical performance with center contact resistance less than 3 mO, outer contact resistance less than 2 mO, and VSWR of 1.25 MAX across the operating frequency range. Mechanically, it provides a center contact retention force of 6 lbs minimum, coupling torque of 20 lbf-in minimum, and durability exceeding 500 cycles. The connector operates reliably across a temperature range of -55°C to +155°C and is constructed from brass body with phosphor bronze contact pin plated with gold, making it suitable for demanding RF and microwave applications requiring robust, repeatable connections.

Product Highlights:

Potential Applications:

Search Keywords: EZ240TMX

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Fairview Microwave

Part No:

EZ-240-TM-X

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694010

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Package Type:

Bag

IN STOCK: 21

Ships today, if you order in

BONDED Quantity: 0

Manufacturer Stock: 0

Stock lot only:

Minimum Order Quantity: 5

MOQ for out of Stock Qty:

Multiple: 1

Factory Lead-Time 2 Weeks

This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.

Price (USD)

Qty

Unit Price

$17.82

$15.61

$14.64

$14.48

100

$14.33

250

$14.18

500 +

$14.04

Tools/3D Models

Product Guides

Datasheet
