SM4265 by fairview microwave
Image is representational - see mfr. specs

SM4265

Fairview Microwave

SMA Male (Plug) to N Female (Jack) Adapter, Passivated Stainless Steel Body, 1.25 VSWR ...

Datasheet
RoHS Non-Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SM4265 is an SMA male to N female RF adapter from Fairview Microwave designed to enable connections between two incompatible connector types. The adapter operates across a frequency range from DC to 18 GHz with excellent VSWR performance of 1.25:1 maximum and 50 ohm impedance. It features gold-plated beryllium copper contacts with 1.3 µm minimum plating thickness, PTFE insulation, and passivated stainless steel body materials, with an operating voltage rating of 335 Vrms AC and dielectric withstand voltage of 1,000 Vrms AC. The adapter measures 1.28 inches (32.51 mm) in length, weighs 0.0585 lbs (26.54 g), and operates reliably across a temperature range of -45°C to +120°C. This adapter is ideal for general-purpose RF testing, equipment protection during frequent connect/disconnect cycles, and enabling between-series connections in microwave and millimeter-wave applications.

Search Keywords: SM4265

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Fairview Microwave
Part No:
SM4265
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag

IN STOCK: 10

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$80.82
5
$72.65
10
$70.63
25
$65.22
50
$65.07
100
$63.61
250 +
$61.36
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
