FTR-F3AA012E-HA by fcl components america, inc. (fcai)
Image is representational - see mfr. specs

FTR-F3AA012E-HA

FCL Components America, Inc. (FCAI)

Power Relay 12VDC 5A SPST-NO(20.3x7x15)mm THT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

FTR-F3AA012E-HA is a 1-pole slim-type power relay designed for high-density mounting with a compact 7mm width and 142mm² mounting space. The relay features a 12V DC coil with 720O resistance (±10%), 200mW rated power, and AgNi contact material rated for 5A at 250VAC or 30VDC (resistive load). It provides excellent insulation with a 6mm clearance and creepage distance between coil and contacts, 4kV dielectric strength, and 10kV surge strength, conforming to IEC 60065 standards. The relay operates reliably over a temperature range of -40°C to +70°C with mechanical life exceeding 5×106 operations and electrical life of 100×10³ operations at rated load, making it suitable for industrial control, automation, and switching applications requiring compact, sealed relay solutions.

Search Keywords: FTRF3AA012EHA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
FCL Components America, Inc. (FCAI)
Part No:
FTR-F3AA012E-HA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Mounting:
Through Hole
Termination Style:
Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
720 Ohm

IN STOCK: 2,926

Can Ship immediately

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 35 Weeks

Price (USD)

Qty
Unit Price
50
$0.870
250
$0.779
500
$0.761
1,000
$0.745
2,500
$0.729
5,000
$0.720
7,500
$0.719
10,000 +
$0.716
Suppliers Standard Package
