AH165-JM2B22A by fuji electric
Image is representational - see manufacturer specifications

AH165-JM2B22A

Fuji Electric

Switch Key Lock N.O./N.C. 4PST 90° Flat Key Quick Connect/Solder 1000000Cycles Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AH165-JM2B22A is an oil-tight selector switch manufactured by Fuji Electric, featuring a key operator with rectangular bezel and 2-position 90-degree maintained operation. This switch provides 2NO+2NC (2 normally open + 2 normally closed) contact configuration with direct opening action, designed for reliable performance in harsh industrial environments. The switch is mounted with a washer and nut assembly, accommodating panel thickness up to 4 mm maximum, and features a compact dimension of 37.5 mm depth and 24 mm width. The AH165 series oil-tight design ensures protection against moisture and contaminants, making it ideal for machine tools, industrial machines, control panels, and distribution panels where durability and safety are critical requirements.

Search Keywords: AH165JM2B22A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Fuji Electric
Part No:
AH165-JM2B22A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509035
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
2
Angle of Throw:
90 °
Key Removable Positions:
Left/Right
Switch Configuration:
N.O./N.C.
Pole Throw Configuration:
4PST
Contact Rating @ Voltage:
N/A
Terminal Type:
Quick Connect/Solder
Bezel Style:
Rectangular
Operating Temperature:
-10 to 70 °C
Body Orientation:
Straight

IN STOCK: 7

Ships today, if you order in

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$77.52
5
$69.16
10
$67.10
25
$61.58
50
$61.43
100
$59.95
250 +
$57.64
