AH165-RJM2A22A by fuji electric
Image is representational - see manufacturer specifications
Fuji Electric Authorized Distributor

AH165-RJM2A22A

Switch Key Lock N.O./N.C. 4PST 90° Flat Key Quick Connect/Solder 1000000Cycles Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AH165-RJM2A22A is an oil-tight 2-position selector switch manufactured by Fuji Electric, designed for industrial control applications requiring sealed operation in harsh environments. This switch features a key operator with round bezel in the A position (removable key location), maintained operation mode, and a 2NO+2NC (2 normally open + 2 normally closed) contact arrangement. The switch is mounted using a washer and nut configuration with a maximum panel thickness of 4 mm and a mounting hole diameter of 24 mm. As part of the AH165 series, this selector switch is oil-tight rated and UL, CSA, TÜV, and CCC approved, making it suitable for machine tools, industrial machines, control panels, and distribution panels where reliable switching and environmental protection are critical.

Search Keywords: AH165RJM2A22A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Fuji Electric
Part No:
AH165-RJM2A22A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509035
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
2
Angle of Throw:
90 °
Key Removable Positions:
Left
Switch Configuration:
N.O./N.C.
Pole Throw Configuration:
4PST
Contact Rating @ Voltage:
N/A
Terminal Type:
Quick Connect/Solder
Bezel Style:
Round
Operating Temperature:
-10 to 70 °C
Body Orientation:
Straight

IN STOCK: 0

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$152.24
5
$140.88
10
$134.84
20
$129.30
50
$125.86
100 +
$124.20
