35-146 by gc electronics
Image is representational - see manufacturer specifications
GC Electronics Authorized Distributor

35-146

The 35-146 is a heavy-duty DPDT toggle switch with an On-On function. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 35-146 is a heavy-duty DPDT (Double Pole, Double Throw) toggle switch featuring an On-On circuit function. It is rated for 20A at 125VAC and 10A at 277VAC, with a power rating of 1-1/2 HP. This switch is constructed with a metal bat-style actuator, a 0.470-inch bushing, and utilizes screw terminals for secure wiring connections. Designed for a 0.500-inch mounting hole, it is well-suited for industrial controls and other applications requiring a robust, high-current switching solution.

Search Keywords: 35146

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
GC Electronics
Part No:
35-146
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
ID
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
20@125VAC A
Actuator Style:
Bat Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.19 x 18.9 x 53.6 mm
Operating Temperature:
N/A

IN STOCK: 86

Can Ship immediately

On Order: 25   can ship 9/9/26

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$13.39
25
$12.72
40
$11.06
100 +
$10.05
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
