19001-03UL by grayhill

19001-03UL

Grayhill

Rotary Switch - SP3T - 3 Positions - 1 Deck - 1 Poles per Deck - 15A(AC)/1A(DC) 120VAC/DC - Flatted (6.35mm Dia) Actuator - Solder Lug - Panel Mount. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 19001-03UL from Grayhill is panel mount single pole three throw (SP3T) rotary switch with 3 positions, 12.70mm long flatted (6.35mm Dia) actuator and solder lug terminals. This rotary switch has 1 deck and 1 poles per deck. The 19001-03UL has 15A, 120V AC ratings and 1A, 120V DC ratings. Dimensions of this switch are: 50.8 mm x 50.8 mm x 46.36 mm.

Search Keywords: 1900103UL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
19001-03UL
RoHS:
Yes
HTS:
8536509025
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
3
Pole Throw Configuration:
SP3T
Actuator Length:
12.7 mm
Dimension:
50.8 x 50.8 x 46.36 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
15@120VAC A

IN STOCK: 28

Ships today, if you order in

MOQ for out of Stock Qty: 7

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$71.678
5
$70.607
7
$69.546
13
$56.166
19
$53.807
25 +
$52.726
