2201 by grayhill
Image is representational - see mfr. specs

2201

Grayhill

The 2201 is a momentary, snap-action miniature pushbutton switch with SPST-N.O. circuitry and solder lug terminals. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2201 is a Series 2000 snap-action miniature pushbutton switch featuring a red button and SPST-Normally Open circuitry. It is designed for momentary contact with an extremely fast make-and-break action, confirmed by an audible click, and has solder lug terminals. This switch is rated to handle 10 Amps at 115 Vac or 5 Amps at 220 Vac for a lifecycle of 25,000 operations. It exhibits a low contact resistance of 25 milliohms or less and an insulation resistance of at least 1,000 megohms. With its robust electrical ratings and long operational life, it is suitable for various panel-mount applications requiring reliable, momentary switching.

Search Keywords: 2201

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
2201
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509030
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
N.O.
Contact Rating @ Voltage:
10A@115 VAC
Actuator Style:
Round Plunger
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
22.35 x 22.35 x 48.34 mm

IN STOCK: 48

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$39.87
5
$37.32
10
$36.21
25
$34.76
50
$33.66
100
$28.12
250 +
$26.87
