30-103 by grayhill
Image is representational - see mfr. specs

30-103

Grayhill

Switch Push Button N.O. SPST Round Button 0.15A 24VDC Momentary Contact Solder Lug Panel Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 30-103 is a butt contact pushbutton switch designed for snap-in panel mounting with a yellow button color option. It features a sealed SPST (Single Pole Single Throw) momentary contact configuration with gold-plated brass contacts and a butt contact system for reliable electrical connection. The switch is constructed with 45% glass-filled nylon for the button, housing, base, and plunger, with tinned music wire springs and silicone rubber seals for durability and environmental protection. It offers 500,000 actuations cycles, operates reliably from -40°C to +80°C, and is rated for 150 milliamps at 24 VDC with a maximum contact resistance of 25 milliohms. This switch is ideal for industrial control panels, instrumentation, and applications requiring sealed, momentary-contact switching with high reliability and long operational life.

Search Keywords: 30103

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
30-103
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509030
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Unthreaded
Switch Configuration:
N.O.
Contact Rating @ Voltage:
0.15A@24 VDC
Actuator Style:
Round Button
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
17.53 x 17.53 x 19.81 mm

IN STOCK: 657

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$11.24
25
$10.19
50
$9.73
100
$8.25
250
$7.81
500
$7.01
1,000 +
$6.83
Log in for special pricing Click for Quote Price Match Request
