44M30-02-1-12N by grayhill
Image is representational - see mfr. specs

44M30-02-1-12N

Grayhill

Switch Rotary SP12T 12 Flatted Shaft Solder Lug 1A 115VAC 115VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 44M30-02-1-12N is a Series 44 multi-deck rotary switch featuring a 1-inch diameter with 1 Amp contact rating and non-shorting (N-type) contacts. This switch is designed with rugged construction to ensure reliable operation throughout the equipment's service life, and is available in both standard UL-recognized and military-qualified (MIL-S-3786/04) versions. The switch incorporates a 3/8-32 UNEF-2A threaded stud with integral assembly nut, a 0.375-inch diameter shaft with bushing keyway, and non-turn tab features for secure panel mounting. Key dimensional specifications include a 0.625-inch diameter flange, 0.376-inch shaft diameter, and adjustable stop washer options with optional knurled nut securing. This rotary switch is ideal for applications requiring multiple deck configurations, precise position selection, and reliable switching in demanding industrial, military, and aerospace environments where durability and performance consistency are critical.

Search Keywords: 44M3002112N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
44M30-02-1-12N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
12
Pole Throw Configuration:
SP12T
Actuator Length:
11.1 mm
Dimension:
29.51 x 31.07 x 57.02 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
1@115VAC 28VDC A

IN STOCK: 10

Ships today, if you order in

MOQ for out of Stock Qty: 3

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$128.99
3
$128.67
5
$115.79
8
$101.32
10 +
$99.29
Log in for special pricing Click for Quote Price Match Request
