44M45-01-1-04N by grayhill
Image is representational - see mfr. specs

44M45-01-1-04N

Grayhill

Switch Rotary SP 4 Flatted Shaft Solder Lug 5A 115VAC 28VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 44M45-01-1-04N is a multi-deck rotary switch manufactured by Grayhill, designed for rugged, long-life operation in demanding applications. This 1-inch diameter switch is rated for 1 ampere continuous current and features military-qualified construction per MIL-S-3786/04 specifications. The switch incorporates a 3/8-32 UNEF-2A threaded shaft with integral assembly nut, non-turn tab dimensions of 0.125 ± 0.003 inches wide by 0.031 ± 0.003 inches thick, and a bushing keyway of 0.066 ± 0.002 inches wide by 0.036 ± 0.003 inches deep. Available in multiple deck configurations with adjustable stops and various contact options (non-shorting or shorting), this switch is ideal for military, aerospace, and industrial control applications requiring reliable multi-position selection with precise mechanical detents.

Search Keywords: 44M4501104N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
44M45-01-1-04N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
4
Pole Throw Configuration:
SP4T
Actuator Length:
11.1 mm
Dimension:
31.07 x 31.07 x 48.24 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
45 °
Contact Rating @ Voltage:
5@115VAC A
  Possible Replacement options available.  See Alternatives

IN STOCK: 10

Ships today, if you order in

MOQ for out of Stock Qty: 3

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$109.67
3
$109.41
5
$98.46
8
$86.16
10 +
$84.43
