44M90-03-2-02N by grayhill
Image is representational - see mfr. specs

44M90-03-2-02N

Grayhill

The 44M90-03-2-02N is a military-qualified, 3-deck rotary switch with a 90° angle of throw, 2 poles per deck, and 2 non-shorting positions per pole. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 44M90-03-2-02N is a Series 44 multi-deck rotary switch designed for high-reliability applications. This military-qualified switch features 3 decks, each configured for 2 poles and 2 non-shorting positions, operating with a 90-degree angle of throw and continuous rotation. The switch is rated to carry 10 amps continuously and has a mechanical life expectancy of 100,000 cycles. Built with diallyl phthalate materials and qualified to MIL-DTL-3786/SR04 standards for an operating temperature range of -65°C to 85°C, it provides durable switching for military and other demanding equipment.

Search Keywords: 44M9003202N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
44M90-03-2-02N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
2
Pole Throw Configuration:
DPDT
Actuator Length:
11.1 mm
Dimension:
29.51mm x 31.07mm x 65.81 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder Lug
Angle of Throw:
90 °
Contact Rating @ Voltage:
5@115VAC A

IN STOCK: 7

Can Ship immediately

MOQ for out of Stock Qty: 3

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$172.96
3
$170.36
5
$153.33
8
$134.16
10 +
$131.48
Log in for special pricing Click for Quote Price Match Request
