50MB90-01-2-02N by grayhill
Image is representational - see mfr. specs

50MB90-01-2-02N

Grayhill

The 50MB90-01-2-02N is a Series 50 military-style rotary switch with 2 poles, 2 positions per pole, and a 90-degree angle of throw. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 50MB90-01-2-02N is a single-deck, military-qualified rotary switch from the Grayhill Series 50. It is configured with 2 poles, 2 positions per pole, non-shorting contacts, and a 90-degree angle of throw. This model features a screwdriver-slotted shaft, solder lug terminals, and is qualified to MIL-S-3786/20 standards. Electrically, it is rated to switch loads up to 200 mA at 28 Vdc (resistive) and has a continuous contact carry rating of 6 amperes. With a life expectancy of 25,000 cycles and robust construction, it is designed for reliable performance in various manual switching applications.

Search Keywords: 50MB9001202N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
50MB90-01-2-02N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
2
Pole Throw Configuration:
DPDT
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 35.46 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
90 °
Contact Rating @ Voltage:
0.2@28VDC A

IN STOCK: 16

Can Ship immediately

MOQ for out of Stock Qty: 7

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$46.77
5
$46.65
7
$46.54
13
$37.58
19
$36.00
25 +
$35.28
Log in for special pricing Click for Quote Price Match Request
