56D36-01-2-AJN by grayhill

56D36-01-2-AJN

Grayhill

Switch Rotary DP Flatted Shaft Solder Lug 0.2A 115VAC 30VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL part 56D36-01-2-AJN is a precision rotary switch featuring a DP (Double Pole) configuration and a flatted shaft design. This switch is designed to be soldered onto a circuit board using solder lug terminals. It has a ratings of 0.2A at 115VAC and 30VDC, making it suitable for a variety of low-power applications. With its high-quality construction and reliable performance, this rotary switch is a great choice for industries requiring precision control and reliable switching.

Search Keywords: 56D36012AJN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
56D36-01-2-AJN
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
N/A
Pole Throw Configuration:
DP5T
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 28.07 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
36 °
Contact Rating @ Voltage:
0.2 A

IN STOCK: 77

Ships today, if you order in

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$28.160
10
$20.919
25
$19.302
50
$18.313
100
$17.603
250
$16.264
500 +
$15.738
