56DP30-01-1-AJN by grayhill

56DP30-01-1-AJN

Grayhill

Switch Rotary SP Flatted Shaft PC Pins 0.2A 115VAC 30VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL part 56DP30-01-1-AJN is a reliable and versatile rotary switch designed for various applications. It features a single-pole configuration with a flatted shaft and PC pins for easy installation. With a maximum current rating of 0.2A, it is suitable for low-power electrical systems. This switch can handle up to 115VAC or 30VDC voltage, making it compatible with a wide range of devices. Trust in GRAYHILL's reputation for quality and durability when using the 56DP30-01-1-AJN rotary switch in your next project.

Search Keywords: 56DP30011AJN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
56DP30-01-1-AJN
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
N/A
Pole Throw Configuration:
SP12T
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 25.46 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount/Through Hole
Body Orientation:
Straight
Terminal Type:
PC Pins
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.2 A

IN STOCK: 25

Ships today, if you order in

On Order: 250   can ship 1/19/26

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$22.526
10
$17.386
25
$15.708
50
$14.482
100
$13.730
250
$12.556
500 +
$11.876
