56SDP36-01-1-AJN by grayhill

56SDP36-01-1-AJN

Grayhill

Switch Rotary SP Flatted Shaft Solder Lug 0.2A 115VAC 30VDC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL 56SDP36-01-1-AJN is a high-quality rotary switch designed for various applications. It features a flatted shaft and solder lug terminals for easy installation. With a maximum current rating of 0.2A and voltage ratings of 115VAC and 30VDC, this switch offers reliable performance in both AC and DC circuits. Its compact and durable design ensures long-lasting use. Upgrade your electronic projects and enjoy seamless switching functionality with the GRAYHILL 56SDP36-01-1-AJN rotary switch.

Search Keywords: 56SDP36011AJN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
56SDP36-01-1-AJN
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
N/A
Pole Throw Configuration:
SP10T
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 28.07 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
36 °
Contact Rating @ Voltage:
0.2 A

IN STOCK: 1,000

Ships today, if you order in

Factory Lead-Time 8 Weeks

Price (CAD)

Qty
Unit Price
1
$50.564
10
$43.810
25
$31.163
50
$31.010
100
$30.856
250
$30.703
500 +
$30.550
