71B30-01-6-02N

Grayhill

A Series 71 multi-deck rotary switch with a 30° angle of throw, featuring one deck, six poles per deck, and two non-shorting positions per pole. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 71B30-01-6-02N is a single-shaft, multi-deck rotary switch from the Series 71 family. This specific configuration is designed with a 30° angle of throw, one deck, six poles, and two positions per pole. It utilizes non-shorting (break-before-make) contacts and features a 1/4 inch diameter shaft (Style B). The switch is rated to carry 4 amperes with a maximum contact temperature rise of 20°C. With a stop strength of 10 pound-inches and gold-plated contacts, this switch provides reliable performance in various circuit selection and control applications.

Search Keywords: 71B3001602N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
71B30-01-6-02N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
2
Pole Throw Configuration:
6PDT
Actuator Length:
9.53 mm
Dimension:
19.05 x 19.05 x 36.78 mm
Actuator Style/Diameter:
Flatted Shaft/6.36
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.3@115VAC A

IN STOCK: 13

Ships today, if you order in

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$38.82
5
$36.49
10
$35.49
25
$34.17
50
$33.16
100
$27.02
250 +
$24.42
