76PSB04ST by grayhill

76PSB04ST

Grayhill

Switch DIP ON OFF SPST 4 Piano 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRAYHILL part 76PSB04ST is a DIP switch designed for ON/OFF operations. It features a Single-Pole, Single-Throw (SPST) configuration with 4 piano-style switches. This switch is capable of handling a current of 0.15A and a voltage of 30VDC. With PC pins for easy installation, it offers a long lifespan of 2000Cycles/SwitchCycles. The switch has a standard pitch of 2.54mm and can be mounted on a PCB using a through-hole connection. It is conveniently packaged in a tube for easy handling and storage.

Search Keywords: 76PSB04ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
76PSB04ST
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
21
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Piano
Actuator Length:
N/A
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.15@30VDC A
Contact Plating:
Gold/Nickel Barrier
Terminal Pitch:
2.54 mm

IN STOCK: 162

Ships today, if you order in

On Order: 1,275   can ship 12/31/25

Minimum Order: 21

Multiple: 21

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
21
$3.135
63
$1.056
105
$1.051
252
$1.040
504
$1.035
1,008
$1.030
2,520
$1.025
5,019 +
$1.020
